3D
With exclusive technology from Dabi Atlante and innovative algorithms, the AXR Eagle Edge Dental Tomograph, in its PRO line, is prepared for high-demand workflows, providing a complete solution in a single product. This equipment offers intelligence, precision, and more accurate diagnostics, delivering performance that will impress even the most demanding professionals.
4 Configuration Options:
– PAN + TOMO (SFOV)
– PAN + TOMO + TELE (SFOV)
– PAN + TOMO (MFOV)
– PAN + TOMO + TELE (MFOV)
Tomographic Volumes:
– **SFOV**: 5×5Ø ENDO, 9×6Ø MAXILLA OR MANDIBLE, 9×9Ø FULL ARCH, 14×9 FULL ARCH + ZYGOMATIC
– **MFOV**: 5×5Ø ENDO, 9×6Ø MAXILLA OR MANDIBLE, 9×9Ø FULL ARCH, 16×9Ø EXTENDED MANDIBLE, 16×15Ø SKULL, 16×21Ø FULL FACE
Motion Correction (PMC):
The Eagle Edge algorithm automatically corrects the image, ensuring high-quality exams, preventing retakes, and offering greater accuracy for diagnostics.
MAR:
The Eagle Edge Pro line features three levels of processing that can be selected to correct distortions from gutta-percha, implants, and/or extensive prosthetics and metallic restorations, in addition to automatic metal reduction.
UHD Mode for Endodontics:
The Eagle Edge offers different resolutions with isotropic voxel ranging from 75μm to 400μm.
Stability and usability
Eagle Edge has new head positioners with 4 support points for better patient stability during exams. Simple to use and easy to position, the set of head positioners was designed to facilitate the clinical routine, making the execution in sequence faster.
3 axis movement
The latest generation movement system that includes three axes (two orthogonal directions and one rotation) which allows greater flexibility in the elaboration of radiographic profiles, optimization of the thickness of the cutting plane and constant vertical magnification.
Eagle Smart Contrast
Innovative algorithm that works in all regions of the image, treating and improving the contrast of each area individually. The result is a homogeneous and noise-free image, allowing the visualization of details and, consequently, better diagnosis.
DICOM Server
The Dicom Server tool of the Eagle software allows the instantaneous sending of the images generated by the equipment to image storage and sharing systems in physically different locations.
Eagle Eye
During the performance of a panoramic radiograph, hundreds of images are generated and assembled into a final image. Eagle Eye software features an innovative function (algorithm) that scans all processed images, seeking the best definition of focus in order to deliver a final image with greater detail and definition, especially in the region of the incisors and canines, TMJ and root canals.
